| Place of Origin: | China |
| Brand Name: | Terui |
| Certification: | CE |
| Model Number: | SFA/AWS A5.1 E6013 TERUI CJ421 |
| Minimum Order Quantity: | 1 Ton |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard export packaging |
| Delivery Time: | 3-10 working days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10000 tons per month |
Details
SFA/AWS A5.1 E6013 TEMO CJ421
Approved by: ABS CCS LR CE
Description:A rutile type electrode for all positional welding, with good weld appearance on both butt and fillet welds for the good flowing properties of the weld metal. Good slag detachability and low spatter. Even at low welding currents, it can still keep stable arc, makes the electrode very suitable for sheet metal welding.
Application: Used to weld low carbon steel structures, particularly suitable for sheet steel and short weld welding.
Welding Position:
Diameters: 2.0mm, 2.5mm, 3.2mm, 4.0mm, 5.0mm.
Packaging: 0.5kg, 1kg, 2kg, 5kg and blister etc.
Typical Mechanical Properties:
Tensile strength(MPa): 490
Yield stress(MPa): 396
Elongation (%): 26
Impact values(≥47J/-20℃): 82
Note:No need bake before using, but please bake 30-60 minutes in 150℃ if the electrodes is humid.
